In structural engineering, stud, plate, and noggins constitute essential structural elements pivotal for an array of construction applications. Utilised in framing walls, supporting ceilings and floors, and enhancing the overall structural stability of buildings—be they residential, commercial, or industrial—these components are indispensable.
Ausdeck specialises in manufacturing these structural elements, available in multiple thicknesses such as 0.8mm, 1.0mm, 1.2mm, and 1.5mm, to meet diverse engineering criteria, including those for cyclone-resistant structures. We offer these components in customisable lengths with optional pre-punched holes or in standard lengths for immediate purchase.
Manufactured from premium materials like Truecore®, alu-zinc, and galvanised steel, our offerings ensure durability, robustness, and engineering precision. Further, they are non-combustible, termite-resistant, warp-resistant, and free from chemical treatments, guaranteeing both safety and long-term investment value.
Using quality, high-tensile Truecore®, alu-zinc and galvanised steel our stud, plate and noggins are designed to adhere to the AS 1397 Australian standard (450MPA minimum yield stress).
Our stud, plate and noggins are available in 50mm, 75mm, 90mm & 100mm sizes to suit a range of construction applications.
We manufacture and deliver stud, plate and noggin within your specified timeframe, minimising downtime for our clients.
| Sizes | 50, 75, 90, 100 |
| Profiles | Stud, Plate & Noggin |
| Lengths (m) | Max. length 8.0m |
| Material | Truecore®, alu-zinc and galvanised |
| Gauge | 0.8, 1.0, 1.2, 1.5 |
| Standard | AS1397 |
| Tolerances (mm) | +\-2mm |
| Size | Material | |
| Stud, Plate & Noggin | 50mm X 0.8 | Alu-zinc |
| 50mm X 1.0 | Truecore / Alu-zinc | |
| 50mm X 1.2 | Truecore / Alu-zinc | |
| 50mm X 1.5 | Galvanised | |
| 75mm X 0.8 | Alu-zinc | |
| 75mm X 1.0 | Truecore / Alu-zinc | |
| 75mm X 1.2 | Truecore / Alu-zinc | |
| 75mm X 1.5 | Galvanised | |
| 90mm X 0.8 | Alu-zinc | |
| 90mm X 1.0 | Truecore / Alu-zinc | |
| 90mm X 1.2 | Truecore / Alu-zinc | |
| 90mm X 1.5 | Galvanised | |
| 100mm X 0.8 | Alu-zinc | |
| 100mm X 1.0 | Truecore / Alu-zinc | |
| 100mm X 1.2 | Truecore / Alu-zinc | |
| 100mm X 1.5 | Galvanised |
The primary functions of stud, plate, and noggins are to provide structural integrity to various construction applications. These components are instrumental in framing both interior and exterior walls, supporting ceilings and floors, and enhancing the overall architectural resilience of residential, commercial, and industrial buildings.
Ausdeck offers these structural elements in a range of thickness specifications, namely 0.8mm, 1.0mm, 1.2mm, and 1.5mm. These options are designed to meet diverse engineering criteria, including requirements for cyclone-resistant structures.
Yes, Ausdeck offers the option of customising these structural components. You can order them cut to specific lengths and with optional pre-punched holes. Alternatively, standardised lengths are available for immediate purchase.
Ausdeck manufactures these structural elements from three premium materials: Truecore®, alu-zinc, and galvanised steel. These materials are selected to ensure durability, robustness, and engineering precision.
Absolutely. Ausdeck’s stud, plate, and noggins are non-combustible, 100% impervious to termites, resistant to dimensional warping, and devoid of any chemical treatments. These features collectively ensure the safety of your construction projects as well as the longevity of your investment.
A noggin is the horizontal bracing that runs between the studs to prevent twisting. While the plate is what is fixed to the top or bottom to secure the stud and noggin.
Yes. Our stud, plate and noggins are designed to comply with the relevant AS1397 Australian standard (450MPA minimum yield stress).
Contact us or request a quote today!
